• Product Profile

  ---

  MLWF Series 400 smoke and dust purifier is an efficient air purifier designed for industrial exhaust smoke and dust. The purifier consists of box,  filter cartridge, dust collector drawer, fan, dust cleaning device and electrical system. By the gravitational action of the fan, the smoke and dust exhaust  is sucked into the air inlet of the equipment by a dust hood. The air inlet and outlet of the equipment are equipped with a flame arrester. Sparks are blocked by the fire arrester, and the smoke and dust gas enter the settling chamber using gravity and upward air flow. Firstly, the coarse dust is directly reduced to the dust collecting drawer, and the particulate dust is trapped on the outside surface by the filter element. The filtering effect of the main filter cartridge can reach 99.7%. Because the high efficiency filtering precision of the main filter core can meet the indoor emission standard, the filtered clean air is directly discharged into the indoor circulation through the air outlet at the top of the purifier.








  Application: It can be used in welding workstation, two welding workstations, grinding, laser cutting, girth welding, etc.




  Product characteristics

  ---

  1. Made of high-quality cold-rolled steel sheet with beautiful and practical appearance.


  2. High-efficiency filter can reach accuracy of 0.3u and  efficiency of 99.7%.   The replacement cycle of filter material is long and the cost is low.

  3. Imported fan, energy saving and environmental protection, long service life.

  4. The inspiratory arm rotates at 360 degrees.

  5. Compact structure, small area, caster design, easy to move.

  6. Filter element cleaning method: manual cleaning and automatic cleaning are optional.
